ACE SDP63-250EU
В продаже Защитные амортизаторы ACE ACE SDP63-250EU оптом и в розницу. Нашли дешевле? Предоставьте свою цену, Мы сформируем более выгодное предложение. При заказе от 3000р., доставка по Самаре - БЕСПЛАТНО! Возможна отправка товара в любую точку РФ транспортной компанией.
Цена:
Технические характеристики
Crane Installations, Optimized Characteristic Energy capacity 43,200 Nm/cycle Stroke 250 mm Technical data
| Energy capacity 43,200 Nm/cycle Reacting Force 190,000 N Return Force min. 1,500 N Return Force max. 18,000 N R Side Load Angle max. 1.8 ° Impact velocity range 0.5 m/s to 4.6 m/s. Other speeds on request. Operating temperature range -20 °C to +60 °C. Other temperatures on request. Mounting in any position Positive stop Integrated Material Outer body: painted steel, Rod end button: steel, Piston tube: hard chrome plated steel Damping medium HLP 46 Filling pressure approx. 5 bar. Rod return by integrated nitogen accumulator. | Note The shock absorber can be pushed through its stroke. In creep speed conditions the shock absorber provides minimal resistance and there is no braking effect. On request Special oils, special flanges, additional corrosion protection etc. |
