ACE MA50EUM
В продаже Гидравлический контроль подачи ACE ACE MA50EUM оптом и в розницу. Нашли дешевле? Предоставьте свою цену, Мы сформируем более выгодное предложение. При заказе от 3000р., доставка по Самаре - БЕСПЛАТНО! Возможна отправка товара в любую точку РФ транспортной компанией.
Цена:
Технические характеристики
Adjustable Energy capacity 5.5 Nm/cycle Stroke 7.2 mm Technical data
| Energy capacity 5.5 Nm/cycle Energy capacity 13,550 Nm/h Effective weight min. 4.50 kg Effective weight max. 20 kg Return Force min. 3.0 N Return Force max. 6.0 N Return Time 0.3 s Side Load Angle max. 2 ° Impact velocity range At speeds of 0.3 m/s the maximum allowed energy is approx. 2 Nm. Where higher energies occur use a shock absorber for the initial impact. Avoid high impact velocities. Operating temperature range 0 °C to 66 °C Mounting in any position Positive stop Integrated Adjustment Hard impact at the start of stroke, turn towards 9 or PLUS. Hard impact at the end of stroke, turn towards 0 or MINUS. Material Outer body: nitride hardened steel, Piston rod: steel with black oxide finish or nitride hardened Damping medium oil, temperature stable | Note Damper is preset at delivery in a neutral position between hard and soft. Safety information External materials in the surrounding area can attack the seal components and lead to a shorter service life. Please contact ACE for appropriate solution suggestions. On request Nickel-plated, weartec finish (seawater resistant) or other special options available on request. |
